OEM 24-Tube Brushless Controller for Heavy Cargo Tricycle
  • OEM 24-Tube Brushless Controller for Heavy Cargo Tricycle
  • OEM 24-Tube Brushless Controller for Heavy Cargo Tricycle
  • OEM 24-Tube Brushless Controller for Heavy Cargo Tricycle
  • OEM 24-Tube Brushless Controller for Heavy Cargo Tricycle
  • OEM 24-Tube Brushless Controller for Heavy Cargo Tricycle

OEM 24-Tube Brushless Controller for Heavy Cargo Tricycle

Payment Type:
T/T
Incoterm:
FOB
Min. Order:
1 Piece/Pieces
Transportation:
Ocean,Land
Share:
  • Product Description
< >
Overview
Product Attributes

Brand: KEHUAN

Origin: China

Certification: ISO 9001:2015

Warranty Period: Other

Place Of Origin: China

Tube Count:: 24

Supply Ability & Additional Information

Packaging: Carton box with foam protection inside

Transportation: Ocean,Land

Place of Origin: China

Certificate: ISO 9001:2015

HS Code: 8504409990

Payment Type: T/T

Incoterm: FOB

Packaging & Delivery
Selling Units:
Piece/Pieces
Package Type:
Carton box with foam protection inside
Heavy cargo tricycles fail at the weakest link — the controller. When a 600–800kg load meets a 15° slope, current demand spikes beyond what mid-range controllers can sustain. Thermal throttling kicks in, torque drops, the vehicle stalls on the incline, and the driver is stranded. For B2B buyers sourcing a 24 tube brushless controller 50A for cargo tricycle, the question is not just rated current — it is whether the controller holds that current under sustained heavy-load, high-grade operation without cutting power.

The KH 24-tube brushless controller is built for exactly this condition. With a 40A/45A current range across the standard variant and up to 60A/70A/80A on the high-power square wave configuration, all running on universal 48V/60V/72V platforms, this controller delivers the torque headroom that heavy cargo and construction tricycle fleets require. Undervoltage protection at 41V/51V/61V preserves battery packs through daily deep-discharge cycles.

24 Tube Brushless Controller 50A For Cargo Tricycle

Technical Specifications



Core Parameters


Parameter Value
Tube Count 24
Voltage 48V / 60V / 72V
Undervoltage Protection 41V / 51V / 61V
Current Limit 40A / 45A (standard) — 60A / 70A / 80A (high-power variant)
Rated Power 1200W (standard) — 1200W / 1500W / 1800W (high-power variant)
Accelerator Voltage 0.8V – 3.6V
Wire Diameter 6mm²
Operating Temperature -20°C – +45°C
Shell Material Standard shell
Color Customizable for bulk orders
Origin China
Certifications ISO 9001:2015, GB/T 18488.2, High-tech enterprise (Xuzhou)


Compatibility Guide



Motor Compatibility


Motor Type Compatibility Notes
Brushless DC motor (square wave) Fully compatible Default configuration
PMSM motor (sine wave) Compatible with firmware update Contact factory for PMSM mapping
1200W rated motors Fully compatible Primary target power class
1500W – 1800W rated motors Fully compatible High-power variant required
Below 1200W (800W–1000W) Compatible Consider 18-tube variant for cost efficiency


Vehicle Compatibility


Vehicle Type Typical Motor Typical Motor Suitability
Heavy cargo tricycle (1.3m–1.5m bed) 1200W 500–800kg Primary target
Construction site transport 1200W–1500W 400–700kg Fully compatible
Municipal / sanitation tricycle 1200W 300–600kg Fully compatible
Ultra-heavy cargo (1.5m+ bed) 1800W+ 800kg+ Consider 30/36-tube variant

24 Tube Brushless Controller For Steep Slope E-Trike

Comparison

24-Tube vs 18-Tube vs 30/36-Tube — Matching Tube Count to Load

Parameter 18-Tube 24-Tube  30/36-Tube
Current Limit 40A–45A 40A–80A 70A–120A
Rated Power 800W–1000W 1200W–1800W 1500W–3000W
Target Load 300–600kg cargo 500–800kg heavy cargo / construction 800kg+ industrial
Wire Diameter Terminal 6mm² 10mm²
Price Point Mid-range Upper mid-range Premium
Fleet ROI Standard cargo Best value for heavy cargo / municipal Industrial / special vehicles
24-tube is the right choice when 18-tube is consistently throttling under load. If drivers report speed drop on inclines or under full cargo weight, the 18-tube controller is hitting its current ceiling. 24-tube provides the headroom without the cost and wiring complexity of 30/36-tube industrial units.

Square Wave vs MOSFET Configuration — Buyer Terminology
Buyers searching for a 24 MOSFET brushless controller for construction tricycle are specifying the same product using international electronics terminology. "24 tube" and "24 MOSFET" refer to the same 24 power transistor power stage — "tube" is the Chinese manufacturing convention, "MOSFET" is the international standard term. The KH 24-tube controller uses 24 MOSFETs in its power stage, and both search terms lead to this product.

24 MOSFET Brushless Controller For Construction Tricycle

Why Choose Us



Sustained High Current — No Throttling on Gradient

Standard 18-tube controllers run 40A–45A. Under 600kg+ cargo load on a 10–15° slope, that current ceiling creates a torque shortfall — the controller hits its limit and throttles output to protect itself. The KH 24-tube controller's 40A/45A standard range and 60A/70A/80A high-power variant provide the headroom that 24 tube brushless controller for steep slope e-trike applications demand. Full current delivery at grade, no mid-slope stall, no driver intervention required.


1200W–1800W Power Range — Built for the Heaviest Loads

12-tube controllers top out at 500W. 18-tube at 1000W. The KH 24-tube platform starts at 1200W and scales to 1800W on the high-power variant — covering the full range of heavy cargo, construction equipment, and municipal tricycle applications. Buyers who have outgrown 18-tube performance without needing the cost premium of 30/36-tube units find the 24-tube variant is the optimal step-up.


13 Years of Controller-Only Focus

Kehuan has manufactured Electric tricycle controllers since 2012 — not motors, not batteries, not accessories. Controller technology is our core competency, backed by >5% annual R&D investment and a university-industry partnership with Guilin University of Electronic Technology since 2016. 1,000+ B2B clients across Southeast Asia, South Asia, and the Middle East rely on Kehuan controllers for daily fleet operation.


Integrated Drive System Supply

Kehuan supplies complete electric tricycle drive systems — not just controllers. When you source from us, you also gain access to compatible Electric Motor units, 12 Tube Brushless Controller variants for lighter fleet configurations, and Electric Tricycle Differential Box assemblies — all designed to work together, eliminating cross-supplier compatibility risks.

24 Tube Color 4-Light Controller

Contact Us

Your heavy cargo and construction tricycle fleet needs a controller that holds current under the worst load conditions. The KH 24-tube brushless controller delivers 40A–80A across 48V/60V/72V platforms — built for the loads, gradients, and duty cycles that standard controllers cannot sustain.

Contact Kehuan for:

  • Bulk pricing (50+ units)
  • Standard vs high-power variant selection guidance
  • OEM/ODM customization inquiry
  • Technical compatibility consultation

Kehuan Electric — 13 years of Electric Tricycle Controller manufacturing, 1,000+ B2B clients, ISO 9001:2015 certified.
